Solar Charging Mode (MPPT)
MODEL
CPS3000ECH48A
CPS5000ECH48A
CPS5000ECH48A-P
Efficiency
98.0% max.
Battery Voltage
48V
Max. PV Array Open
Circuit Voltage
145Vdc
PV Array MPPT Voltage Range
60~115Vdc
Min battery voltage for PV charge
34Vdc
Standby Power Consumption
2W
Battery Voltage
Accuracy
+/-0.3%
PV Voltage Accuracy
+/-2V
Charging Algorithm
3-Step
Joint Utility and Solar Charging
Max Charging Current
45Amp
140Amp
Default Charging Current
30Amp
60Amp
Table 4, General Specifications
MODEL
CPS3000ECH48A
CPS5000ECH48A
CPS5000ECH48A-P
Safety Certification
CE
Operating Temperature Range
0°C to 55°C
Storage temperature
-15°C~ 60°C
Humidity
5% to 95% Relative Humidity (Non-condensing)
Dimension, mm
400 x 315 x 130
455 x 350 x 130
Net Weight, kg
8.5
11.5
11.5
