38
20
23
21
22
15
NOTE! For the car seat to offer optimum protection, shoulder belts
should fit the body as closely as possible (15) and the hip belts
should should run as low as possible so they are thight against
the pelvis.
NOTE! Ensure that shoulder belts (15) are not twisted.
• Put your child into the car seat.
• Place shoulder belts (15) directly over your child’s shoulders.
• Place both buckle tongues (21) together and lock them in place
in belt buckle (20) with an audible “CLICK”.
• Fasten the clip with an audible “CLICK”.
• Push the closed clip down toward belt buckle.
• Pull cautiously on central adjustment belt (23) in order to tighten
shoulder belts (15) until they fit your child’s body.
• Position the Clip right under the shoulder pads.
• Undo the belt buckle (20) by pressing the red button firmly.
• Open the clip by pressing the release button and pulling both
parts apart.
The belt tongues (21) can now be fixed sideward on the cover
(22). This area is magnetic.
