12
x
y
u
w
x
y
u
w
v
i
With the ISOFIX CONNECT System you can secure the child seat safely in
the car and thus make your child safer. Your child is further protected by the
security of your car‘s three-point automatic seat belt.
NOTE
located between the backrest and the seat of the car. If you are in any doubt,
If it is difficult to access the ISOFIX anchorage points (i) of your car, and to protect
the seat cover you can permanently fit the ISOFIX guides (u) provided in both
anchorage points. In many cars it is more effective to install the ISOFIX guides (u)
in an opposing direction.
To secure the CYBEX JUNO 2-FIX correctly, observe the following instructions:
NOTE
second connector
NOTE! Please refer to the section „PLACING THE CHILD SEAT IN THE CAR“.
INSTALLATION OF THE CHILD SEAT WITH ISOFIX CONNECT
SYSTEM
Activate the handle (v) on the underside of the child seat.
Pull out the ISOFIX connectors (w) as far as possible.
Turn the connectors 180°, so that they show in the direction of the ISOFIX
GUIDES (u).
You can now secure your child in the child seat; see „SECURING THE CHILD“
Push the two ISOFIX connectors (w) into the GUIDES (u) until they lock into place
on the anchorage points (i) with an audible „CLICK“.
Make certain that the child seat is securely fixed in place by trying to pull it out.
The green safety indicator (x) must be clearly visible on both red release buttons
(y).
You can now use the handle (v) on the underside of the child seat to adjust the
position of the seat.
