It is the responsibility of the facility owner/owner of the equipment to ensure that there is appropriate clearance around each machine
to allow for safe use and passage.
In compliance with the ADA (American Disabilities Act) there must be clear floor space of at least 30 by 48 inches and be served by an
accessible route for at least one of each type of exercise equipment. If the clear space is enclosed on three sides (e.g., by walls or the
equipment itself), the clear space must be 36 by 48 inches.
All other machines must have a clear floor space of 23” for all access point on the machine, unless shown in the Owner’s Manual.
Environment
Humidity and Static Electricity
The unit is designed to function normally in an environment with a relative humidity range of 30% to 75%. The unit can be shipped
and stored in a relative humidity range of 10% to 90%.
Climatic dry air may cause static electricity. During workout, user may experience a shock due to build up of static electricity on the
body and the discharge path of the unit. If static electricity is experienced, increase humidity to a comfortable level through the use of
a humidifier.
Do not install, use or store the unit in an area of high humidity, such as in the vicinity of a steam room, sauna, indoor pool or outdoors.
Exposure to extensive water vapor, chlorine and/or bromine could adversely aect other parts of the unit.
Temperature
The unit is designed to function normally in an environment with an ambient temperature range of 50° F (10° C) to 104° F (40° C). The
unit can be shipped and stored in an environment with an ambient temperature range of 32° F (0° C) to 140° F (60° C).
Verify parts list below
Qty Part Number Description Diagram
4 12090-322 Foot Pad
1 14000-401 Decal, Weight Plate
19 4000C101
Weight Stack Plate (Standard
Stack)
24 4000C101
Weight Stack Plate (Heavy
Stack)
Tools Required
• 7/32” Allen wrench
Page 8 of 22
