Cybex VR3 12180 Tricep Press Owner’s Manual
Service
Page 6-4
1 1 11010-334 COUNTERWEIGHT
2 1 11040-006 TOP WEIGHT ASSY 10
3 1 11040-440 KNOB
4 1 11040-568 CLAMP BLOCK INSERT
5 1 11090-210 CLAMP
6 2 11100-360 END CAP, BEARING HOUSING
7 1 12000-339 PIN, DETENT
8 1 12000-342 PIN, DETENT
9 1 12000-344 INSERT, PLASTIC
10 1 12000-345 FOOT PAD, 4.00 x 7.00
11 1 12000-467 PULLEY COVER
12 2 12000-369 RING, HANDLE GRIP
13 2 12000-387 EXTRUSION, INC WT CHANNEL
14 1 12000-392 CHANNEL, INCREMENT WEIGHT
15 1 12000-393 CHANNEL, INCREMENT WEIGHT
16 1 12000-395 TOP CAP
17 2 12000-396 END CAP
18 4 12000-398 SPACER
19 1 12000-401 PANEL INSERT
20 1 12000-560 DECAL, WT PLATE (30 - 290)
21 4 12050-346 WHEEL, PLASTIC ROLLER
22 1 12050-348 GUIDE, ROLLER
23 1 12070-394 DECAL, INDICATOR
24 4 12090-322 FOOT PAD
25 6 12100-303 BUMPER
26 2 12102-330 INSERT, INCREMENT WEIGHT
27 1 12120-328 PIVOT SHAFT
28 1 12180-200 MAIN FRAME
29 1 12180-201 INPUT ARM
30 1 12180-203 SEAT BOTTOM
31 1 12180-204 DETENT BAR
32 1 12180-324 BLOCK, STOP
33 1 12180-332 LINK BAR
34 1 12180-335 DECAL, ADJUSTING
35 1 12190-354 GAS SPRING MOUNT
36 2 12210-347 GUIDE ROD CAP
37 2 12210-348 GUIDE ROD CAP
38 2 12210-350 WT ROD .625 DIA X 49.53
39 2 12230-207 W HANDLE
40 1 4715-346 COMPRESSION SPRING .72 x 1.50 LG
41 1 51198 WARRANTY BOOKLET (NOT SHOWN)
42 2 610A-350 END CAP
43 2 BS070208 COMPRESSION SPRING
44 1 CM000211 DECAL, PATENT PENDING
45 1 EZ000008 GAS SPRING 100N
46 2 FB030232 BEARING, RADIAL 17 mm EX. RACE
47 2 FB050211 BRG FLG .38 X .50 .25 LG
48 4 FB130214 BRG SLV 1.00 X 1.12 X .75
49 2 FC030006 TOLERANCE RING 1.575 ID
50 157” GB000202 STANDARD WEIGHT STACK BELT
.95 WIDE
51 6 GP000209 PULLEY ASSEMBLY-3.50
52 6 HC700428 BHSCS .375-16 X 2.25
53 2 HC700430 BHSCS .375-16 X 2.50
54 2 HC700432 BHSCS .375-16 X 2.75
55 2 HD303312 S BOLT .250 X .500 .190-10-24
56 2 HF449064 INSERT 1.12 X .250-20 UNC
57 12 HF579000 PANEL FASTNER, 10-24 U TYPE
58 2 HN575100 LOCKNUT .190-No 10-24
59 3 HN664900 NUT, HEX SELF-LOCKING
.312-18 ZINC
60 6 HN704901 LOCKNUT, .375-16 NYLON
61 2 HN704902 LOCKNUT, .375-16 NYLON
62 2 HP306720 PIN COILED .25 x 1.25
63 1 HS328300 LOCKWASHER SPLIT .312
64 2 HS347600 WASHER, SAE .375
65 10 HT512517 TAP SC 10-24 X 1.00 TYPE WB
PN HD PHIL BLK
66 4 HT570410 SCREW, PNH TORX 10-24 X 375,
BLACK
67 12 HX570412 BHSCS, 10-24 X .50, SS
68 2 HX-60184 BALL STUD, .312 - 18
UNC x 10 mm
69 2 HX620420 BHSCS .250-20 X 1.250 SS
70 3 HY740000 SET SCREW
71 4 JC620415 BHSCS .250-20 X .75
72 2 JC620422 BHSCS .250-20 x 1.50
73 4 JC700412 BHSCS .375-16 X .50
74 2 JC700420 BHSCS .375-16 X 1.25
75 2 JC702820 SHCS .375-16 X 1.25
76 1 JD343330 S BOLT .375 X 2.50 .312-18
77 4 JD383315 SHOULDER BOLT .500 x .75
.375-16 UNC
78 4 JS347400 LOCKWASHER, INT TOOTH .375
79 2 PP130002 INSERT, DOMED PLASTIC
80 2 PR060005 BUMPER, WEIGHT
81 2 12230-353 GRIP 1.62 OD X 1.20 ID
82 2 4000Y316-X* CAUTION DECAL
83 1 4605-381-X* WARNING DECAL
84 2 8500-026* CAUTION DECAL
85 1 12180-598-X* PLACARD
86 1 4520-362-X* CAUTION DECAL
87 1 4800-176 BACK PAD
88 1 4800-172 SEAT PAD
89 1 11000-407-X* DECAL, INCREMENT WEIGHT
90 1 13000-402 WATER BOTTLE HOLDER MOUNT
91 1 13000-400 WATER BOTTLE HOLDER
92 1 HT552515 TAP SCREW 8-16 X .75
93 1 12180-999-X* OWNER’S MANUAL (NOT SHOWN)
94 1 11040-790 DECAL, MADE IN U.S.A.
