Cyclo Vac Tradition E100 - Installing Inlets - Dos & Donts

A
B
A
B
11
Installation
INSTALLING INLETS
When installing your vacuum inlets, we recommend that the principle of electric
polarity be taken into account. Ensure that the wire connected onto contact A on
inlet 1 is the same as that connected to contact A on inlet 2, and so on. Do not
cross, reverse or interchange wires.
Dos & Don’ts
inlet 1
inlet 2
