Schematic – Other Models
1. Circuit Breaker
2. Reset (DL series only)
3. LEDs (DL series only)
4. Low Voltage Connector
5. Serial Number
6. Air Intake
7. Air Exhaust
2
3
4
5
6
1
7
min. 30 cm (12")
min. 30 cm (12")
Recommende 40 cm (16")
With muf er turned down,
min. 30 cm (12")
min. 30 cm (12")
min. 30 cm (12")
Muf er turned up, 184 cm (73.5")
Muf er turned down, 150 cm (60")
95 cm (38")
