Preface
Your new Cyclo Vac central vacuum system was designed and manufactured in
Blainville, Quebec, by the largest central vacuum cleaner manufacturer in Canada.
With over forty years of experience in the  eld, we provide a high-quality, state-of-
the-art product, and guarantee your complete satisfaction. Our extensive network
of quali ed professionals ensures  rst quality service near you. Contact us for the
location of the Cyclo Vac authorized service center in your area.
Schematic – E100
1. Circuit Breaker
2. Low Voltage Connector
3. Serial Number
4. Air Intake
5. Air Exhaust
min. 30 cm (12") min. 30 cm (12")
min. 5 cm (2")
min. 30 cm (12")
Recommende 40 cm (16")
With muf er turned down,
min. 30 cm (12")
Muf er turned up, 106 cm (42.5")
Muf er turned down, 154 cm (61.5")
2
3
1
4
5
90 cm (36")
