The image bellow is how the Speed controller looks like inside the
plastic box. All the electrical devices on your bike will have been
pre-connected to the controller by the time the bike reaches you.
However, if you ever face problems with your bike, you may want
to open the plastic box and double check that there are no loose
connections on the controller.
In most cases, you do not need to do this. On the other hand, if
you would like to troubleshoot a problem, follow the connections
guide in the next page to understand how your controller is meant
to be set up.
All wires coming out of the controller are either uniquely shaped
or colour coded to prevent wrong connections. All you have to do
is match the colours and shapes. The next page shows a photo of
all the wires and how/where they should be connected.
WARNING: Please do NOT open the metal box of the controller
itself. Doing so will void your warranty and may cause a safety
hazard.
