RIGHT-HAND and LEFT-HAND sides are determined by the bike handle;
Right-hand corresponds to the right handle.
In order for this product to t on various dierent widths of bottom
brackets, there are several spacers that come with the kit. These spacers
are designed to provide the bottom brackets with necessary spacing
between the this product brackets.
Note that the spacers can be adjusted to accommodate dierent chain
lines as needed.
Before you begin, ensure that you have removed the original crankset
and bottom bracket from the bicycle frame. This includes any bearings,
bottom bracket cups, inserts, and/ or adaptors that might have been
tted. Clean up any grease and/ or debris from your frame's bottom
bracket shell and wipe o any excess dirt from your frame around the
areas where the drive unit and its peripherals will be installed.
Preparing Your Frame
This product can be mounted in any position around the bicycle frame's
bottom bracket shell that supports the drivetrain's movement without
obstruction. The chainring assembly together with your bicycle chain
must be able to move freely and not come into contact with other
components or areas on the bicycle frame.
Mounting Options
Operating Notice
The motor body must be supported against either the bicycle frame or
supporting structures in order to prevent the motor body from
movement during use.
WARNING
