22
PATTERN MODE
LEVEL 1 LEVEL 2 LEVEL 3
HDR Output Emulator (Cont.) Tx AVI Colour Space [Analytic Data]
Sink EDID supports HDR
SCDC Output Monitor [Analytic Data]
TX Port Controls +5V Out On/Off Follow TMDS
Always On
HDCP Output On/Off
*PoR
On
Off
HDCP Output Version v1.4
v2.2
HDCP AKE_Send_Stored_km() On
Off
HDCP Counter Reset
SCDC CED Counter Read On
Off
!
TX doesn't read sink CH0 ~ 3 Error-Counter.
SCDC CED Always Read On
Off
!
TX ignores sink CED_Update flag.
SCDC CED Ch Auto Clear On
Off
!
While sink CED_ Update flag=1, TX auto clears its CH0 ~ 3 Error-
Counter and reads a new counter from the sink.
Output Resolution See “Test Timing List” below
(T66 1080p60)
OSD Settings H Position 0% ~ 100% (10%)
V Position 0% ~ 100% (10%)
Transparency
(Solid ~ Transparent)
0 ~ 7 (4)
To Next Page
