COMMANDS
DESCRIPTION VARIABLES
$HDCP_OUT_VER N1

Set the HDCP version to use on the
unit’s HDMI output.
Available values for N1:
V1.4 [HDCP v1.4]
V2.2 [HDCP v2.2]
!
Affects Pattern mode only.
$HDCP_OUT_VER?

Display the current HDCP version for
the output port.
$HDR_EOTF N1

Set the HDR EOTF (Electro-Optical
Transfer Function) mode.
Available values for N1:
SDR [Traditional Gamma,
SDR Luminance Range]
HDR [Traditional Gamma,
HDR Luminance Range]
2084 [SMPTE ST 2084]
RSVD [Reserved for future use]
$HDR_EOTF?

Display the current HDR EOTF mode.
$HDR_MCLL N1

Set the maximum HDR content light
level.
N1 = 0 ~ 65500 [100 unit
increments]
$HDR_MCLL?

Display the current maximum HDR
content light level.
$HDR_MFALL N1

Set the maximum HDR frame-average
light level.
N1 = 0 ~ 65500 [100 unit
increments]
$HDR_MFALL?

Display HDR maximum light level of
frame-average.
$HDR_SET N1

Select the current HDR setting. N1 = 1 ~ 3
