Cypress CYW43353 - Page 71

Document No. 002-14949 Rev. *E Page 71 of 113
PRELIMINARY
CYW43353
Output low voltage @ 2 mA VOL – –0.45 V
For VDDIO = 3.3V:
Input high voltage VIH 2.00
– –V
Input low voltage VIL
– –0.80 V
Output high voltage @ 2 mA VOH VDDIO – 0.4
– –V
Output low Voltage @ 2 mA VOL
– –0.40 V
RF Switch Control Output Pins
3
For VDDIO_RF = 3.3V:
Output high voltage @ 2 mA VOH VDDIO – 0.4
– –V
Output low voltage @ 2 mA VOL
– –0.40 V
Output capacitance C
OUT
– – 5 pF
1. The CYW43353 is functional across this range of voltages. Optimal RF performance specified in the data sheet, however, is guaranteed only for 3.13V <
VBAT < 4.8V.
2. The maximum continuous voltage is 4.8V. Voltage transients up to 6.0V (for up to 10 seconds), cumulative duration over the lifetime of the device are
allowed. Voltage transients as high as 5.0V (for up to 250 seconds), cumulative duration over the lifetime of the device are allowed.
3. Programmable 2 mA to 16 mA drive strength. Default is 10 mA.
Table 26. Recommended Operating Conditions and DC Characteristics (Cont.)
Parameter Symbol
Value
UnitMinimum
Typic
al Maximum
