Table 29. Local Oscillator Performance
Parameter Minimum Typical Maximum Unit
LO Performance
Lock time –72–s
Initial carrier frequency tolerance – ±25 ±75 kHz
Frequency Drift
DH1 packet – ±8 ±25 kHz
DH3 packet – ±8 ±40 kHz
DH5 packet – ±8 ±40 kHz
Drift rate –520kHz/50 s
Frequency Deviation
00001111 sequence in payload
1
1. This pattern represents an average deviation in payload.
140 155 175 kHz
10101010 sequence in payload
2
2. Pattern represents the maximum deviation in payload for 99.9% of all frequency deviations.
115 140 – kHz
Channel spacing –1–MHz
Table 30. BLE RF Specifications
Parameter Conditions Minimum Typical Maximum Unit
Frequency range – 2402 2480 MHz
RX sense
1
1. Dirty TX is On.
GFSK, 0.1% BER, 1 Mbps – –95.5 – dBm
TX power
2
2. BLE TX power can be increased to compensate for front-end losses such as BPF, diplexer, switch, etc.). The output is capped at 12 dBm out. The BLE TX
power at the antenna port cannot exceed the 10 dBm specification limit.
– – 8.5 – dBm
Mod Char: delta F1 average – 225 255 275 kHz
Mod Char: delta F2 max
3
3. At least 99.9% of all delta F2 max frequency values recorded over 10 packets must be greater than 185 kHz
– 99.9––%
Mod Char: ratio – 0.8 0.95 – %
