Cypress CYW43353 - Page 80

Document No. 002-14949 Rev. *E Page 80 of 113
PRELIMINARY
CYW43353
RX sensitivity IEEE 802.11ac
(10% PER for 4096 octet PSDU)
a,5.
Defined for default parameters: 800 ns
GI and non-STBC.
40 MHz channel spacing for all MCS rates
MCS0 – –91.5 – dBm
MCS1 – –89.0 – dBm
MCS2 – –87.2 – dBm
MCS3 – –84.0 – dBm
MCS4 – –80.8 – dBm
MCS5 – –76.3 – dBm
MCS6 – –74.7 – dBm
MCS7 – –73.3 – dBm
MCS8 – –68.9 – dBm
MCS9 – –67.6 – dBm
RX sensitivity IEEE 802.11ac 20/40/80
MHz channel spacing with LDPC
(10% PER for 4096 octet PSDU) at
WLAN RF port. Defined for default
parameters: 800 ns GI, LDPC coding,
and non-STBC.
MCS7 20 MHz – –77.4 – dBm
MCS8 20 MHz – –74.7 – dBm
MCS7 40 MHz – –74.6 – dBm
MCS8 40 MHz – –71.6 – dBm
MCS9 40 MHz – –70.1 – dBm
MCS7 80 MHz – –71.5 – dBm
MCS8 80 MHz – –68.1 – dBm
MCS9 80 MHz – –66.0 – dBm
Blocking level for 3 dB RX sensitivity
degradation (without external
filtering)
6
776–794 MHz CDMA2000 – –24 – dBm
824–849 MHz
7
cdmaOne – –25 – dBm
824–849 MHz GSM850 – –15 – dBm
880–915 MHz E-GSM – –16 – dBm
1710–1785 MHz GSM1800 – –18 – dBm
1850–1910 MHz GSM1800 – –19 – dBm
1850–1910 MHz cdmaOne – –26 – dBm
1850–1910 MHz WCDMA – –26 – dBm
1920–1980 MHz WCDMA – –28.5 – dBm
2500–2570 MHz Band 7 – –45 – dBm
2300–2400 MHz Band 40 – –50 – dBm
2570–2620 MHz Band 38 – –45 – dBm
2545–2575 MHz XGP Band – –45 – dBm
In-band static CW jammer immunity
(fc – 8 MHz < fcw < + 8 MHz)
RX PER < 1%, 54 Mbps OFDM,
1000 octet PSDU for:
(RxSens + 23 dB < Rxlevel < max input level)
–80 – – dBm
Input in-band IP3
a
Maximum LNA gain – –15.5 – dBm
Minimum LNA gain – –1.5 – dBm
Maximum receive level
@ 2.4 GHz
@ 1, 2 Mbps (8% PER, 1024 octets) –3.5 – – dBm
@ 5.5, 11 Mbps (8% PER, 1024 octets) –9.5 – – dBm
@ 6–54 Mbps (10% PER, 1024 octets) –9.5 – – dBm
@ MCS0–7 rates (10% PER, 4095 octets) –9.5 – – dBm
@ MCS8–9 rates (10% PER, 4095 octets) –11.5 – – dBm
LPF 3 dB bandwidth – 9 – 36 MHz
Table 32. WLAN 2.4 GHz Receiver Performance Specifications (Cont.)
Parameter Condition/Notes Minimum Typical Maximum Unit
