Cypress CYW43353 - Page 84

Document No. 002-14949 Rev. *E Page 84 of 113
PRELIMINARY
CYW43353
RX sensitivity IEEE 802.11ac
(10% PER for 4096 octet PSDU)
a
Defined for default parameters: 800 ns
GI and non-STBC.
40 MHz channel spacing for all MCS rates
MCS0 – –90.5 – dBm
MCS1 – –87.4 – dBm
MCS2 – –85.3 – dBm
MCS3 – –82.1 – dBm
MCS4 – –79 – dBm
MCS5 – –73.9 – dBm
MCS6 – –72.4 – dBm
MCS7 – –72.3 – dBm
MCS8 – –67.9 – dBm
MCS9 – –66.6 – dBm
RX sensitivity IEEE 802.11ac
(10% PER for 4096 octet PSDU)
a
Defined for default parameters: 800 ns
GI and non-STBC.
80 MHz channel spacing for all MCS rates
MCS0 – –87 – dBm
MCS1 – –83.9 – dBm
MCS2 – –81.9 – dBm
MCS3 – –78.1 – dBm
MCS4 – –75 – dBm
MCS5 – –73 – dBm
MCS6 – –68.5 – dBm
MCS7 – –68.5 – dBm
MCS8 – –64.3 – dBm
MCS9 – –62.7 – dBm
RX sensitivity IEEE 802.11ac 20/40/80
MHz channel spacing with LDPC (10%
PER for 4096 octet PSDU) at WLAN
RF port. Defined for default
parameters: 800 ns GI, LDPC coding
and non-STBC.
MCS7 20 MHz – –76.4 – dBm
MCS8 20 MHz – –73.7 – dBm
MCS7 40 MHz – –73.6 – dBm
MCS8 40 MHz – –70.6 – dBm
MCS9 40 MHz – –69.1 – dBm
MCS7 80 MHz – –70.5 – dBm
MCS8 80 MHz – –67.1 – dBm
MCS9 80 MHz – –65.0 – dBm
Blocking level for 1 dB RX sensitivity
degradation (without external filtering)
2
776–794 MHz CDMA2000 –21 – – dBm
824–849 MHz cdmaOne –20 – – dBm
824–849 MHz GSM850 –12 – – dBm
880–915 MHz E-GSM –12 – – dBm
1710–1785 MHz GSM1800 –15 – – dBm
1850–1910 MHz GSM1800 –15 – – dBm
1850–1910 MHz cdmaOne –20 – – dBm
1850–1910 MHz WCDMA –21 – – dBm
1920–1980 MHz WCDMA –21 – – dBm
2500–2570 MHz Band 7 –21 – – dBm
2300–2400 MHz Band 40 –21 – – dBm
2570–2620 MHz Band 38 –21 – – dBm
2545–2575 MHz XGP Band –21 – – dBm
Input in-band IP3
a
Maximum LNA gain – –15.5 – dBm
Minimum LNA gain – –1.5 – dBm
Table 34. WLAN 5 GHz Receiver Performance Specifications (Cont.)
Parameter Condition/Notes Minimum Typical Maximum Unit
