D-Link DAP-1330 Quick Install Guide

8 DAP-1330 Install Guide
Once you connect, the login page will appear. Enter your password and click
Log in. By default the password is blank.
Note: If this is the rst time logging in to the DAP-1330, you will be directed to the
Wizard automatically. Skip to step 6.
4
Note: The default IP address is 192.168.0.50. Once the DAP-1330 connects to your
router, it will get assigned a new IP address based on your router/network’s DHCP
settings. You will need to log in to your router and view the DHCP table to see what
IP address was assigned to the DAP-1330. The MAC address is printed on the label
on the device.
The home page will display your current status. A green check mark represents
a successful connection to your wireless router or Access Point (AP). A red X
means there is not a connection to your router or access point. Click the Uplink
Router icon.
5

D-Link DAP-1330 Specifications

General

Product color	White
LED indicators	Yes
Maximum data transfer rate	100 Mbit/s
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3u
Interface	Wi-Fi/Ethernet
Ethernet LAN (RJ-45) ports	1
Security algorithms	WPA, WPA2, WPS
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Operating altitude	5 - 95 m
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, IC, CE, C-Tick, CB, UL

Weight and Dimensions

Weight	86.9 g
Dimensions (WxDxH)	77 x 55.5 x 34 mm
