D-Link DAP-1360 Quick Installation Guide

DAP-1360 Quick Installation Guide
Configuring Connection to the Internet
(Router Mode Only)
!
You should configure your WAN connection in accordance with data
provided by your Internet service provider (ISP). Make sure that you
have obtained all necessary information prior to configuring your
connection. Otherwise contact your ISP.
1. Go to the Net / WAN page and click the Add button.
2. In the General settings section, select a needed value from the
Connection Type drop-down list.
3. From the Port drop-down list, select the WAN value.
4. Specify a name for your connection (any name for easier identification) in
the Name field.
22

D-Link DAP-1360 Specifications

Power

power input	5V DC/1.2 A
power adapter socket	external power adapter

Operating Environment

operating temperature	0 ˚C to 55 ˚C
storage temperature	10 ˚C to 70 ˚C
operating humidity	10% to 90% non-condensing

Weight and Dimensions

weight	215 grams
dimensions	147.5 x 113 x 31.5 mm
