D-Link DAP-1360 Quick Installation Guide

DAP-1360 Quick Installation Guide
5. If your ISP uses MAC address binding, in the Ethernet section, in the
MAC field, enter the MAC address registered by your ISP upon
concluding the agreement. To set the MAC address of the network
interface card (of the computer that is being used to configure the access
point at the moment) as the MAC address of the WAN interface, click the
Clone MAC Address button ( ). To set the address of a device
connected to the access point's LAN at the moment, select the relevant
value from the drop-down list (the field will be filled in automatically).
6. For connection of PPPoE type: in the PPP section, enter authorization
data provided by your ISP (the username (login) in the Username field
and the password in the Password and Password confirmation
fields), or select the Without authorization checkbox if authorization
is not required.
23

D-Link DAP-1360 Specifications

Power

power input	5V DC/1.2 A
power adapter socket	external power adapter

Operating Environment

operating temperature	0 ˚C to 55 ˚C
storage temperature	10 ˚C to 70 ˚C
operating humidity	10% to 90% non-condensing

Weight and Dimensions

weight	215 grams
dimensions	147.5 x 113 x 31.5 mm
