4D-Link DAP-1525 User Manual
Section 1 - Product Overview
Power Receptor
Receptor for the supplied power
adapter.
USB Port
Use to connect to USB 2.0
printer sharing application.
Hardware Overview
Back View
Ethernet Ports
In AP mode, the Ethernet port is used to
connect to your switch/router. In Client
mode, the Ethernet port is used to connect
your computer to a wireless network.
Mode Switch
Use to switch among 2.4GHz AP,
5GHz AP, and Bridge mode.
