D-Link DAP-1610 Quick Install Guide

6 DAP-1610 Install Guide
Connect Your Wireless Devices
5
6
Your device is now connected to the DAP-1610 and can connect to your wireless
router. If you want to change your network settings, password, etc., follow the
steps on the next page to congure the DAP-1610. To connect additional
devices, repeat step 5.
Your setup is complete!
Extended network
Original network
From your wireless device go to the Wireless Utility to display the available
wireless networks.
The SSID on the DAP-1610 will automatically be assigned the following:
(Your Router’s SSID)-EXT
The Wi-Fi password for the DAP-1610 will be the same as your router.
Repeat step 5 to connect additional Wi-Fi devices to the DAP-1610.

D-Link DAP-1610 Specifications

General

Type	Network transmitter & receiver
WPS push button	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Maximum transfer distance	- m
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	WPA, WPA2
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab
Certification	FCC, IC, CE2. UL
Product color	White
LED indicators	Signal strength, Status, WPS
Ethernet LAN (RJ-45) ports	1
Antenna type	External
Antennas quantity	2
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	50.7 mm
Width	97.9 mm
Height	48.7 mm
Weight	120 g
