D-Link DAP-2610 Quick Install Guide
ENGLISH
DAP-2610 Quick Install Guide
This installation guide provides basic instructions for installing the DAP-2610 Wireless Access
Point on your network. For additional information about how to use the Access Point, please
see the User’s Manual which is available on the CD included in this package or from the
D-Link support website.
System Requirements
Minimum System Requirements:
 CD-ROM Drive
 an Ethernet port, or an installed Ethernet adapter
 Internal Explore 11, Safari 7, Firefox 28, Google Chrome 33 or later versions of these
browsers
1. Package Contents
 DAP-2610 802.11ac Access Point
 Power Adapter
 Mounting Brackets
 Ethernet Cable
 CD-ROM
If any of the above items are missing, please contact your reseller.
Note: Using a power supply with a different voltage than the one included with the DAP-2610
will cause damage and void the warranty for this product.

D-Link DAP-2610 Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Maximum data transfer rate (5 GHz)	867 Mbit/s
Placement	Ceiling, Table, Wall
Certification	FCC IC CE UL
Product color	White
LED indicators	Power, Status
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Input current	1 A
AC input voltage	12 V
Power consumption (max)	12 W
Security algorithms	64-bit WEP, 128-bit WEP, 802.1x RADIUS, SSID, WPA, WPA2
Antennas quantity	2
Antenna direction type	Omni-directional
Antenna gain level (max)	3 dBi
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Package depth	269 mm
Package width	204 mm
Package height	64 mm
Package weight	134.8 g
Pallet width	1200 mm
Pallet length	1101 mm
Pallet height (air)	2047 mm
Pallet gross weight (air)	400210 g
Quantity per pallet (air)	480 pc(s)
Shipping (inner) case width	284 mm
Shipping (inner) case height	224 mm
Shipping (inner) case length	356 mm
Shipping (inner) case weight	3950 g
Shipping (inner) case net weight	2000 g
Number of cartons per pallet (air)	96 pc(s)
Quantity per shipping (inner) case	5 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	170 mm
Height	28 mm
Weight	314 g
