D-Link DAP-2610 User Manual

27
D-Link DAP-2610 Quick Install Guide
PORTUGUÊS
1. Prenda as duas travas nos painel de
teto. Certique-se que as duas travas
estão alinhadas entre si.
2. Use os parafusos fornecidos para xa o
anel de montagem às travas de teto.
3. Plugue o cabo Ethernet na porta LAN
do access point.
4. Coloque a trava macho do DAP-2610
nas travas fêmeas do suporte de
xação. “Clique” o DAP-2610 para
travá-lo na posição.
Trava de Teto
Barra de Teto
Montagem com xação de teto
Instalação

D-Link DAP-2610 Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Maximum data transfer rate (5 GHz)	867 Mbit/s
Placement	Ceiling, Table, Wall
Certification	FCC IC CE UL
Product color	White
LED indicators	Power, Status
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Input current	1 A
AC input voltage	12 V
Power consumption (max)	12 W
Security algorithms	64-bit WEP, 128-bit WEP, 802.1x RADIUS, SSID, WPA, WPA2
Antennas quantity	2
Antenna direction type	Omni-directional
Antenna gain level (max)	3 dBi
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Package depth	269 mm
Package width	204 mm
Package height	64 mm
Package weight	134.8 g
Pallet width	1200 mm
Pallet length	1101 mm
Pallet height (air)	2047 mm
Pallet gross weight (air)	400210 g
Quantity per pallet (air)	480 pc(s)
Shipping (inner) case width	284 mm
Shipping (inner) case height	224 mm
Shipping (inner) case length	356 mm
Shipping (inner) case weight	3950 g
Shipping (inner) case net weight	2000 g
Number of cartons per pallet (air)	96 pc(s)
Quantity per shipping (inner) case	5 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	170 mm
Height	28 mm
Weight	314 g
