Need help?Do you have a question about the D-Link DAP-2610 and is the answer not in the manual?
General| 2.4 GHz | Yes |
|---|---|
| Networking standards | IEEE 802.3ab, IEEE 802.3u |
| Ethernet LAN data rates | 100, 1000 Mbit/s |
| Maximum data transfer rate | 1000 Mbit/s |
| Maximum data transfer rate (5 GHz) | 867 Mbit/s |
| Placement | Ceiling, Table, Wall |
| Certification | FCC IC CE UL |
| Product color | White |
| LED indicators | Power, Status |
| Storage temperature (T-T) | -20 - 65 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 95 % |
| Operating relative humidity (H-H) | 10 - 90 % |
| Input current | 1 A |
| AC input voltage | 12 V |
| Power consumption (max) | 12 W |
| Security algorithms | 64-bit WEP, 128-bit WEP, 802.1x RADIUS, SSID, WPA, WPA2 |
| Antennas quantity | 2 |
| Antenna direction type | Omni-directional |
| Antenna gain level (max) | 3 dBi |
| USB 2.0 ports quantity | 0 |
| Ethernet LAN (RJ-45) ports | 1 |
| Package depth | 269 mm |
| Package width | 204 mm |
| Package height | 64 mm |
| Package weight | 134.8 g |
| Pallet width | 1200 mm |
| Pallet length | 1101 mm |
| Pallet height (air) | 2047 mm |
| Pallet gross weight (air) | 400210 g |
| Quantity per pallet (air) | 480 pc(s) |
| Shipping (inner) case width | 284 mm |
| Shipping (inner) case height | 224 mm |
| Shipping (inner) case length | 356 mm |
| Shipping (inner) case weight | 3950 g |
| Shipping (inner) case net weight | 2000 g |
| Number of cartons per pallet (air) | 96 pc(s) |
| Quantity per shipping (inner) case | 5 pc(s) |
| Harmonized System (HS) code | 85176990 |
Weight and Dimensions| Width | 170 mm |
|---|---|
| Height | 28 mm |
| Weight | 314 g |
