D-Link DAP-2610 User Manual

5
D-Link DAP-2610 Quick Install Guide
ENGLISH
Solid wall or ceiling
Installation
1. Place the mounting bracket on a wall or
ceiling.
5. Plug the Ethernet cable into the LAN
port on the access point.
6. To attach the access point to the
mounting bracket.
2. Mark the points where you will insert the
screws. Take out the mounting ring.
3. Drill holes in the marked points and
insert the plastic wall anchors.
4. Use the supplied screws to attach the
mounting ring to the wall.

D-Link DAP-2610 Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Maximum data transfer rate (5 GHz)	867 Mbit/s
Placement	Ceiling, Table, Wall
Certification	FCC IC CE UL
Product color	White
LED indicators	Power, Status
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Input current	1 A
AC input voltage	12 V
Power consumption (max)	12 W
Security algorithms	64-bit WEP, 128-bit WEP, 802.1x RADIUS, SSID, WPA, WPA2
Antennas quantity	2
Antenna direction type	Omni-directional
Antenna gain level (max)	3 dBi
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Package depth	269 mm
Package width	204 mm
Package height	64 mm
Package weight	134.8 g
Pallet width	1200 mm
Pallet length	1101 mm
Pallet height (air)	2047 mm
Pallet gross weight (air)	400210 g
Quantity per pallet (air)	480 pc(s)
Shipping (inner) case width	284 mm
Shipping (inner) case height	224 mm
Shipping (inner) case length	356 mm
Shipping (inner) case weight	3950 g
Shipping (inner) case net weight	2000 g
Number of cartons per pallet (air)	96 pc(s)
Quantity per shipping (inner) case	5 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	170 mm
Height	28 mm
Weight	314 g
