DAP-400P Quick Installation Guide
Mesh Network Main Device (Master)
In order to configure DAP-400P as a main device of your Mesh network, from
the Connection method list, select the Super Mesh value. Then from the
Device Role list, select the Master value. From the Frequency band list,
select the band where your Mesh network operates.
!
The Super Mesh function cannot operate in both bands simultaneously.
Select one of the bands ( 2.4GHz or 5GHz ) for all devices of the configured
network.
In order to connect your main device to a wired ISP, from the Work mode
list, select the Router value. In this mode you can configure a WAN
connection, set your own settings for the wireless network in the 2.4GHz and
5GHz bands, and set your own password for access to the web-based interface
of the device.
24
