D-Link DCS-4602EV

D-Link DCS-4602EV Quick Installation Guide
11
ENGLISH
To waterproof your camera installation, follow the instructions below. Round Ethernet
cable, a crimping tool, and RJ-45 plugs are required for this procedure.
Waterproong Your Installation
Place the washer around the base of the Ethernet
connector as shown.
Connect the RJ-45 plug into the Ethernet connector, then
screw the waterproof connector to the Ethernet connector
by turning it clockwise for about a half-turn.
Thread bare Ethernet cable through the waterproof
connector as shown.
Crimp an RJ-45 connector onto the end of the cable.
Connect the other end of the Ethernet cable to the
camera's Ethernet port.
