9D-Link DCS-820L User Manual
Section 1: Product Overview
Front View
Hardware Overview
1 Night Vision (IR) LEDs Infrared LEDs illuminate the camera's eld of view at night.
2 Focus Ring Used to adjust the focus.
3 Camera Lens Allows you to record or view video of the surrounding area.
4 Ambient Light Sensor Sensor for ambient (surrounding) light.
5 Front Accent Ring Decorative switchable front accent ring (in blue or pink).
6 Microphone Allows you to record or listen to audio from the surrounding area.
7 Camera Base Camera base for placement on a desktop or wall mounting.
3
1
7
6
4
2
5
