Section 1: Product Overview
Hardware Overview
Front View
Camera Lens
Microphone
IR LEDs (behind cover)
Light Sensor
Microphone Records audio of the surrounding area
Light Sensor The IR-Cut Removable sensor measures the lighting conditions
Camera Lens Records video of the surrounding area
IR LEDs Infrared LEDs illuminate the camera's eld of view at night
Camera Stand Used to mount the camera on at surface
1
2
3
4
5
Camera Stand
1
2
3
4
5
