D-Link DCS-8302LH User Manual

4D-Link DCS-8302LH User Manual
Section 1 - Product Overview
Back
Reset Button Push the recessed button to reset the camera to factory default settings.
microSD Card Slot microSD card slot, supports up to 256 GB.
Power Connector Attach your power adapter to this port to supply power to the device.
Ethernet Port RJ-45 connector for Ethernet connections.
microSD Card Slot
Reset Button
Ethernet Port
Power Connector

D-Link DCS-8302LH Specifications

General

Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Video compression formats	H.264
Sensor type	CMOS
Progressive scan	Yes
Number of sensors	-
Optical sensor size	1/2.9 \
Type	IP security camera
PTZ control	No
Certification	CE, LVD, RCM, FCC Class B, IC, NCC/BSMI
Placement supported	Indoor & outdoor
Connectivity technology	Wired & Wireless
LED type	IR
Night vision distance	5 m
Fixed focal length	3 mm
Minimum illumination	- lx
Audio system	2-way
Wi-Fi standards	802.11g, Wi-Fi 4 (802.11n)
Networking standards	IEEE 802.11g, IEEE 802.11n
Supported network protocols	IPv4, IPv6 dual stack, Bonjour (mDNS and DNS-SD), ONVIF Profile S, RTSP, SRTP (D-Link private), HTTPS
Security algorithms	WPA3
Alert notification type	Snapshot alert message
Motion sensor technology	Passive infrared (PIR) sensor
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
AC input voltage	100 - 240 V
DC output current	1 A
DC output voltage	12
Power source type	AC, DC
AC input frequency	50 - 60 Hz
Power consumption (max)	7 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-20 - 45 °C
Form factor	Bullet
Mounting type	Ceiling/wall
Product color	White
Management software	mydlink app
Number of cameras	1
Harmonized System (HS) code	85258900

Weight and Dimensions

Depth	88 mm
Width	74 mm
Height	138 mm
Weight	250 g
Cable length	3 m
