DCS-933L
ENGLISH
Mount the Camera
Please refer to the steps below to assist you with mounting the camera.
2. Use a athead screwdriver to remove
the base cover from the mounting
base. Place the mounting base where
you want to position the camera and
use a pencil to mark the holes.
3. Depending on the material of the wall
or ceiling, use proper tools to drill two
holes or screws where you marked. If
the wall is made out of concrete, drill
the holes rst, then insert the plastic
anchors to support the screws.
1. The camera needs to be removed to
expose the holes in the mounting
base. Unscrew the camera head
from the mounting base by turning
counterclockwise.
1
We suggest that you congure the camera
before mounting.
2
3
4. Place the mounting base over the
holes that are in the wall. Make sure
to align the mounting base holes with
the holes in the wall. Use the supplied
screws to attach the mounting base to
the surface of the wall.
4
