2
Hardware Installation
System Requirements
• Internet Explorer 6.x or above
• CPU: 800MHz or above
• Memory Size: 128MB (256MB recommended)
• VGA card resolution: 800x600 or above
Note: If using multiple cameras for viewing/recording, the minimum requirements
are a 2GHz or above CPU with 512MB memory and a 32MB video card.
Connect the Ethernet Cable
Connect an Ethernet cable to the Ethernet connector located
on the Internet Camera’s back panel and attach it to the
network.
Attach the External Power Supply
Attach the external power supply to the DC power input
connector located on the Internet Camera’s back panel
(labeled DC 5V 2.5A) and connect it to an AC power outlet.
The LAN LED will light green when there is a good connection to the LAN. The LED will
begin to flash indicating the camera is receiving or sending data.
Power source is confirmed when
the LED Power Indicator on the
Internet Camera is illuminated.
If you connect this camera directly to a PC,
the DCS-950G has an MDI/X port that will allow
you to use either a straight through (included) or cross-
over cable.
To Next Page
