10BASE-T Stackable Hubs
♦ Tandem blade
♦ Grounding type attachment plug rated at 15 A, 250V
When using a 230V power source outside of the U.S., use a cord with the
following characteristics:
♦ 18 AWG
♦ Grounding attachment plug rated at 15A, 250V
♦ The cord should have the appropriate safety approvals for the country
where the equipment will be installed. It should be marked “HAR.”
Be sure the operating environment for the hub is within the following ranges:
♦ Temperature: 32
o
to 122
o
F (0
o
to 50
o
C)
♦ Humidity: 5% to 95% (non-condensing)
Power Connection
To connect power, take the following steps.
1. Plug the female IEC connector of the power cable into the power
connector on the back of the hub.
2. Insert the three-pronged plug on the power module cable into a non-
switched, grounded power outlet on a wall, a power strip, or a
grounded extension cord.
3. When you plug in the power cable, verify that the hub performs the
self test to confirm the hub is operating correctly. To power off the
hub, disconnect the male connector from the outlet. Do not disconnect
the female connector from the hub to power off the hub.
3-2 Setting Up the Hub
