D-Link DFL-260E

4
5
ENGLISH
Using the WebUI
To use the WebUI, the workstation from which
you are managing the device must initially be on
the same subnetwork as the device.
To access the device with the WebUI:
Step 1
Connect your workstation on the LAN1.
Step 2
Ensure your workstation is congured with a
static IP address in the 192.168.10.0/24 subnet.
Note:
Disable pop-up blocking software or add the
management IP address https://192.168.10.1 to
your pop-up blocker’s allow list.
Step 3
Launch your browser; enter the IP address
for the LAN1 interface. (The factory default IP
address is https://192.168.10.1), then press
Enter.
Note: DFL-260E/860E allows either HTTP
or a secure HTTPS connections from any
management host. However, for security
reasons, only a secure HTTPS connection is
allowed by default. For more information about
conguring connections settings, please refer to
the Firewall User Manual.
Browser Version
Microsoft Internet
Explorer
6.0 or higher
Mozilla Firefox 1.0 or higher
Netscape Navigator 8.0 or higher
Table 4. Browser Compatibility
Figure 6. Browser Address
Step 4
Log into the NetDefend Firewall web interface.
The default login information is:
Username: admin
Password: admin
Note: The Language drop-down menu allows
you to select a language for the WebUI. By
factory default, NetDefend Firewall only includes
English. You may upload specic language les
from within the WebUI for additional language
support. Currently, Japanese, Russian,
Simplied Chinese, and Traditional Chinese
language les are available.
Using a Console Connection (RJ-45)
The NetDefend Firewall provides an RJ-45
console port that supports a connection to a
computer or console terminal for monitoring and
conguring the device. This port uses a female
DB-9 connector, implemented as a data commu-
nication terminal equipment (DCE) connection.
To use the console port connection, you need
the following equipment:
1. A terminal or a computer with both a serial
port and the ability to emulate a terminal.
2. A RJ-45-to-DB9 RS-232 cable with female
connector. (included in the package)
3. If your Laptop or PC does not have a RS-232
connector, an converter is required.
Note: DFL-260E/860E does not come with an
RS-232 converter.
Figure 7. Authentication Message
