6
Built-in Antenna
Used to wirelessly
connect to 802.11b
(AirPlus, Air) net-
works.
32-bit connector
This is the connector
that fits into the
Cardbus slot of your
laptop
Power LED
Lights to indicate that
the DWL-650+ is
properly inserted.
Link/Activity LED
Blinks when data is being transmitted
through the wireless connection.
When you restart your com-
puter this Found New Hard-
ware Wizard (Windows XP)
screen will appear:
Click Next
Select Install the
software automatically
(Recommended)
Restart your laptop
Note: Please do not remove the driver CD until the DWL-650+ installation is complete!
