D-Link DIR-645 - Using Window 7 and WPS

120D-Link DIR-645 User Manual
Section 4 - Knowledge Base
Using Window 7 and WPS
The WPS feature of the router can be congured using Windows® 7. Carry out the following steps to use Windows® 7 to congure the WPS feature
of the router:
1. Click the Start button and select Computer from the Start menu.
2. Click the Network option.
3. Double-click the Router.
4. Input the WPS PIN number and click Next.
