D-Link DIR-830L

10D-Link DIR-830L User Manual
Section 2 - Installation
4. Plug one end of the included blue Ethernet cable that came with your router into the yellow port labeled
INTERNET on the back of the router. Plug the other end of this cable into the Ethernet port on your modem.
5. Reconnect the power adapter to your cable or DSL broadband modem and wait for two minutes.
6. Connect the supplied power adapter into the power port on the back of the router and then plug it into a power
outlet or surge protector. Press the power button and verify that the power LED is lit. Allow one minute for the
router to boot up.
7. If you are connecting to a broadband service that uses a dynamic connection (not PPPoE), you may be online
already. Try opening a Web browser and enter a website. A solid light indicates a connection on the Internet port
and the router can connect to the Internet. If the LED is orange, the connection is good but the router cannot
connect to the Internet.
DIR-830L
DIR-830L
Modem
Computer
Modem
Computer
USB
WPS
1
2
3
4
INTERNET
POWER
INTERNET
USB
WPS
1
2
3
4
INTERNET
POWER
INTERNET
