9D-Link DIR-830L User Manual
Section 2 - Installation
1. Turn o and unplug your cable or DSL broadband modem. This is required.
Hardware Installation
2. Position your router close to your modem and a computer. Place the router in an open area of your intended
work area for better wireless coverage.
3. Unplug the Ethernet cable that is connected to your computer from your modem (or existing router if upgrading).
Plug it into the LAN port labeled 1 on the back of your router. The router is now connected to your computer.
Modem
DIR-830L
Computer
USB
WPS
1
2
3
4
INTERNET
POWER
