DIR-841 AC1200 Wave 2 MU-MIMO Wi-Fi Router
with Gigabit WAN Port
User Manual
Overview
LED Mode Description
LAN 1-4
Solid green
A device (computer) is connected to the relevant port,
the connection is on.
Blinking green
Data transfer through the relevant LAN port.
When the router is being loaded, the LEDs are blinking
one at a time.
When the firmware is being upgraded, the LEDs are
blinking two at a time.
No light
The cable is not connected to the relevant port.
WLAN 2.4G
WLAN 5G
Solid green
The router's WLAN of the relevant band is on.
Blinking green
Data transfer through the Wi-Fi network of the relevant
band.
No light
The router's WLAN of the relevant band is off.
WPS
Blinking green
Attempting to add a wireless device via the WPS
function.
No light
The WPS function is not in use.
Page 15 of 209
