10D-Link DIR-880L User Manual
Section 2 - Installation
Wall Mounting
You can mount the DIR-880L on a wall or partition for ease and convenience. To wall mount your device:
Step 1
Screw the provided screws to the wall to which the router will be mounted.
Step 2
Place the mounting holes on the bottom of the device over the screws, and
slide the device into place.
Step 3
Finally, connect the required cables to the device as described on page 11.
