TROUBLESHOOTING
SETUP AND CONFIGURATION PROBLEMS
1. WHAT TO DO IF THE POWER LED IS NOT LIT UP?
Check if the power adapter is properly connected to a wall socket and the back of the switch.
2. WHAT TO DO IF A CONNECTED DEVICE IS NOT DETECTED?
First check if the Port LED is ashing. If the Port LED is not illuminated, try connecting the device
using a di󰀨erent LAN cable.
TECHNICAL SUPPORT
Location Color Status Description
LED Per 1000 BASE-T Port
(Port 1-5)
Green
Solid 1000M Connection
Blinking Data transmission/Activity
Amber
Solid 10/100M Connection
Blinking Data transmission/Activity
O󰀨 Light o󰀨 No link
LED Per 2.5G BASE-T Port
(Port 6-7)
Blue
Solid 2.5G Connection
Blinking Data transmission/Activity
Green
Solid 1000M Connection
Blinking Data transmission/Activity
Amber
Solid 10/100M Connection
Blinking Data transmission/Activity
O󰀨 Light o󰀨 No link
PORT LED CONNECTION SPEED
Link/Act LED INDICATORS

D-Link DMS-107 Specifications

General

Switch type	Unmanaged
Cloud-managed	No
Installed SFP modules quantity	0
2.5G Ethernet (copper) ports quantity	2
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	5
Product color	Black
LED indicators	Yes
Networking standards	-
Ethernet LAN data rates	10, 100, 1000, 2500 Mbit/s
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T, 2500BASE-T
Power source	DC
Input current	0.5 A
DC input voltage	12 V
Power consumption (max)	3.37 W
Forwarding rate	14.88 Mpps
MAC address table	2000 entries
Packet buffer memory	2 MB
Heat dissipation	14.28 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 95 %
Warranty period	5 year(s)

Weight and Dimensions

Depth	82 mm
Width	142 mm
Height	28 mm
Weight	295.2 g
