8D-Link DNS-323 User Manual
Section 1 - Product Overview
Hardware Overview
Front View
Power Button:
Press once to power on the DNS-323. Press and hold the button until it begins to blink to power down the DNS-323.
Drive Lights:
These lights will be solid BLUE when drives are connected but inactive. The lights will blink when the drives are being
accessed, formatted or synchronized. They will illuminate AMBER if a drive has failed.
Network Activity Light:
The Activity Light will be solid BLUE when there is an Ethernet connection. It will blink to indicate LAN traffic.
Power Button
Drive Light Drive Light
Network Activity Light

D-Link DNS-323 - Network Storage Enclosure NAS Server Specifications

General

Device Type	NAS server
Number of Bays	2
Weight	1.5 kg
Network Architecture	Gigabit Ethernet
Supported Drive Types	3.5" SATA I/II
RAID Levels	JBOD, RAID 0, RAID 1
Supported Protocols	HTTP, FTP, SMB, NFS
Max Internal Capacity	4 TB (2 x 2 TB)
Processor	Marvell 88F5182
Memory	64 MB
Power Consumption	25 W (operational)
Operating Temperature	0 to 40°C (32 to 104°F)
Interfaces	1 x 10/100/1000 Gigabit Ethernet, 1 x USB 2.0
Data Transfer Rate	1 Gbps
