9D-Link DNS-323 User Manual
Section 1 - Product Overview
Power Receptacle:
The 12V 3A / 5V 3A power supply connects here.
Ethernet Port:
A Gigabit Ethernet port that connects the DNS-323 to a network.
USB Port:
USB Print Server port for connecting a USB printer.
Drive Eject Lever:
Use the levers to eject the hard drives. The front panel must be removed before ejecting the drives.
Reset Button:
A pinhole button located beside the Ethernet socket is used to reset the DNS-323 to the factory default settings.
Note: After resetting the unit’s configuration you will still have access to the data on your hard drive(s).
Rear Panel (Connections)
Ethernet Port
Power Receptacle
USB Port
Drive Eject Lever
Drive Eject Lever
Reset Button

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the D-Link DNS-323 - Network Storage Enclosure NAS Server and is the answer not in the manual?

D-Link DNS-323 - Network Storage Enclosure NAS Server Specifications

General IconGeneral
Device TypeNAS server
Number of Bays2
Weight1.5 kg
Network ArchitectureGigabit Ethernet
Supported Drive Types3.5" SATA I/II
RAID LevelsJBOD, RAID 0, RAID 1
Supported ProtocolsHTTP, FTP, SMB, NFS
Max Internal Capacity4 TB (2 x 2 TB)
ProcessorMarvell 88F5182
Memory64 MB
Power Consumption25 W (operational)
Operating Temperature0 to 40°C (32 to 104°F)
Interfaces1 x 10/100/1000 Gigabit Ethernet, 1 x USB 2.0
Data Transfer Rate1 Gbps
