Volume
Headset Volume Set the headset calls the volume level.
Speakerphone
Ring Volume
Set the speaker ring the volume grade.
Headset Volume
Offset
Set the headset the Volume the Offset.
Headset Mic
Offset
Set the headset MIC the Offset.
G.729AB Payload
Length
G.729AB Payload Length – Adjusts from 10 – 60 mSec.
G.723.1 Bit Rate Choices are 5.3kb/s or 6.3kb/s.
G.722
Timestamps
Choices are 160/20ms or 320/20ms.
DTMF Payload
Type
Choices are 160/20ms or 320/20ms.
Enable VAD
Enable or disable Voice Activity Detection (VAD). If VAD is enabled, G729
Payload length cannot be set greater than 20 mSec.
Enable MWI Tone
Enable MWI Tone by selecting it
EHS Type Enable EHS Type by selecting it
8.3.4.3 MCAST
It is easy and convenient to use multicast function to send notice to each member of the
multicast via setting the multicast key on the device and sending multicast RTP stream to
pre-configured multicast address. By configuring monitoring multicast address on the
