D-Link DSR-500AC User Manual

D-Link DSR-Series User Manual 202
Section 8 - Security
IPS
Path: Security > Firewall > IPS
The router’s Intrusion Prevention System (IPS) prevents malicious attacks from the internet from accessing
the private network. Static attack signatures loaded to the router allow common attacks to be detected and
prevented. The checks can be enabled between the WAN and DMZ or LAN, and a running counter will allow the
administrator to see how many malicious intrusion attempts from the WAN have been detected and prevented.
Note: The DSR-150/150N routers do not support Intrusion Prevention System.
1. Click Security > Firewall > IPS.
2. Complete the elds from the table below and click Save.
Field Description
Enable Intrusion Detection Toggle to ON to enable intrusion detection.
Enable Intrusion Prevention Toggle to ON to enable intrusion prevention.
LAN and WAN Toggle to ON to detect intrusions between the LAN and WAN interfaces.
DMZ and WAN Toggle to ON to detect intrusions between the DMZ and WAN interfaces.
Number of Signatures
Loaded
Displays the number of signatures loaded.
Save Click it to save your changes.

D-Link DSR-500AC Specifications

General

Firewall	Yes
Firewall security	Port Address Translation (PAT)
Security algorithms	3DES, DES, EAP-PEAP, EAP-TLS, EAP-TTLS, SSID, WEP, WPA, WPA-EAP, WPA-PSK, WPA2, WPA2-EAP, WPA2-PSK, WPS
Authentication method	POP3, LDAP, AD, NT Domain
SIM card slot	No
VPN support	IPSec/PPTP/L2TP/OpenVPN Server
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x
VPN tunnels quantity	95
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	6
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	- Mbit/s
Product type	Tabletop router
Product color	Black
LED indicators	Activity
Power supply	13.1 W
Output current	2.5 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Certification	FCC Class B, CE Class B, RCM, IC, cUL, LVD (EN60950-1)
Mean time between failures (MTBF)	360000 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Routing protocols	OSPF, RIP-1, RIP-2
Supported network protocols	PPoE, L2TP, PPTP, DNS
Antennas quantity	3
Antenna gain level (max)	2 dBi

Weight and Dimensions

Depth	180 mm
Width	280 mm
Height	44 mm
