D-Link DSR-500AC User Manual

D-Link DSR-Series User Manual 33
Section 5 - Connect to the Internet
Static IP
Path: Network > Internet > WAN1 Settings
Select Static IP to manually enter the Internet settings supplied by your Internet Service Provider.
Field Description
IP Address Enter the IP address supplied by your ISP.
IP Subnet Mask Enter the subnet mask supplied by your ISP.
Gateway IP Address Enter the gateway IP address supplied by your ISP.
Primary DNS Server If you selected “Use These DNS Servers”, enter the primary DNS server IP address.
Secondary DNS Server
If you selected “Use These DNS Servers”, enter the secondary DNS server IP address.
MAC Address Source
Select Use Default MAC to use the MAC address from the WAN1 port to associate with your modem/ISP,
Clone your PC’s MAC to use the MAC address of the computer you are currently using to associate with
your modem/ISP, or Use this MAC to manually enter a MAC address.
MAC Address If you selected Use this MAC, enter the MAC address you want to associate with your ISP.
MTU Size Select to use the default MTU value (1500) or select Custom to enter your own value.
Custom MTU Enter a MTU value to optimize performance with your ISP.
Port Speed Select a value from the drop-down menu. The default value is Auto-Sense.
Save Click Save to save and activate your settings.

D-Link DSR-500AC Specifications

General

Firewall	Yes
Firewall security	Port Address Translation (PAT)
Security algorithms	3DES, DES, EAP-PEAP, EAP-TLS, EAP-TTLS, SSID, WEP, WPA, WPA-EAP, WPA-PSK, WPA2, WPA2-EAP, WPA2-PSK, WPS
Authentication method	POP3, LDAP, AD, NT Domain
SIM card slot	No
VPN support	IPSec/PPTP/L2TP/OpenVPN Server
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x
VPN tunnels quantity	95
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	6
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	- Mbit/s
Product type	Tabletop router
Product color	Black
LED indicators	Activity
Power supply	13.1 W
Output current	2.5 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Certification	FCC Class B, CE Class B, RCM, IC, cUL, LVD (EN60950-1)
Mean time between failures (MTBF)	360000 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Routing protocols	OSPF, RIP-1, RIP-2
Supported network protocols	PPoE, L2TP, PPTP, DNS
Antennas quantity	3
Antenna gain level (max)	2 dBi

Weight and Dimensions

Depth	180 mm
Width	280 mm
Height	44 mm
