D-Link DSR-500AC User Manual

D-Link DSR-Series User Manual 211
Section 8 - Security
License Update
Path: Maintenance > Administration > License Update
Certain features can be added to the router by purchasing a license key. An activation code is provided based on
the router’s MAC Address, so it will be unique to that particular device.
Field Description
Free WCF Trial for 90 Days
Click Enable Free Trial. You can use dynamic ltering feature free for 90 days. This option can be
used for once only.
Licenses List
License Model It displays the license model as it relates to the feature being added.
Activation Code It displays the activation code corresponding to this license.
Expires
It displays the date of expiration. Licenses can either have a xed duration, or are perpetual for
the life of this router.
Activation Setup
License Activation Code Enter the new activation code to activate the license.
Activate Click Activate to activate the entered license activation code.
The license update page displays the elds given in the table below:

D-Link DSR-500AC Specifications

General

Firewall	Yes
Firewall security	Port Address Translation (PAT)
Security algorithms	3DES, DES, EAP-PEAP, EAP-TLS, EAP-TTLS, SSID, WEP, WPA, WPA-EAP, WPA-PSK, WPA2, WPA2-EAP, WPA2-PSK, WPS
Authentication method	POP3, LDAP, AD, NT Domain
SIM card slot	No
VPN support	IPSec/PPTP/L2TP/OpenVPN Server
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x
VPN tunnels quantity	95
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	6
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	- Mbit/s
Product type	Tabletop router
Product color	Black
LED indicators	Activity
Power supply	13.1 W
Output current	2.5 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Certification	FCC Class B, CE Class B, RCM, IC, cUL, LVD (EN60950-1)
Mean time between failures (MTBF)	360000 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Routing protocols	OSPF, RIP-1, RIP-2
Supported network protocols	PPoE, L2TP, PPTP, DNS
Antennas quantity	3
Antenna gain level (max)	2 dBi

Weight and Dimensions

Depth	180 mm
Width	280 mm
Height	44 mm
