Powering on the Device

To connect the device to a power source, plug one end of the AC power cord into the AC power connector on

the back panel of the device. Plug the other end into an electrical outlet and switch ON the power switch.

Note: We recommend using a surge protector for the power connection.

Initial Configuration

The wireless controller software is preinstalled on the DWC-2000. When the device is powered on, it is ready

to be configured. It comes with a default factory configuration that allows you to connect to it, but you should

configure the controller for your specific network requirements.

Discovering the Wireless Controller

Using the Web UI

To use the Web UI, the workstation from which you are managing the device must initially be on the same

subnet as the device. You will also need a compatible browser:

Browser Minimum Version

Microsoft

Internet Explorer

9, 10

Mozilla Firefox 23

Apple Safari iOS: 6.1.3

Windows: 5.1.7

Google Chrome 26

To access the device’s Web UI:

1. Connect your workstation to one of the ports labelled LAN (1-4).

2. Ensure your workstation is configured with a static IP address in the 192.168.10.0/24 subnet.

3. Launch your browser and enter the IP address for the LAN interface

(The default IP address is http://192.168.10.1), then press Enter.

4. Log into the wireless controller Web interface. The default login information is:

• Username: admin

• Password: admin

Other manuals for D-Link DWC-2000

Questions and Answers:

Need help?

Do you have a question about the D-Link DWC-2000 and is the answer not in the manual?

General

Security algorithms	802.1x RADIUS, WPA, WPA2
Data transfer rate	1 Gbit/s
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power consumption (typical)	26.95 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Compatible products	DWL-8610AP, DWL-8600AP, DWL-6600AP, DWL-3600AP, DWL-2600AP
Certification	FCC Class A, CE Class A, C-Tick, IC, cUL, LVD
Package depth	504 mm
Package width	444 mm
Package height	110 mm
Package weight	5846 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1095 mm
Pallet height (sea)	2055 mm
Pallet gross weight (air)	250560 g
Quantity per pallet (air)	36 pc(s)
Shipping (inner) case width	396 mm
Shipping (inner) case height	480 mm
Shipping (inner) case length	526 mm
Shipping (inner) case weight	18755 g
Shipping (inner) case net weight	17538 g
Number of cartons per pallet (air)	12 pc(s)
Quantity per shipping (inner) case	3 pc(s)
Harmonized System (HS) code	85176990
