The following table lists the name, color, status, and description of each device LED.
LED
Indicator
Colour Status Description
Power/
Status
Orange/
Green
Solid Orange Power-on process in progress
Solid Green Power-on process complete
Blinking Orange Device has crashed and is in recovery mode
Light Off The device is powered off
Fan Green/
Red
Solid Green The fan is operating normally
Solid Red The fan has failed
USB Green Solid Green The link is good
Blinking Green There is activity on this port
Light Off No link
Tx/Rx
Status of
RJ-45 Port
Green Solid Green Link is present
Blinking Green Port is sending or receiving data
Light Off No link
Link Speed of
RJ-45 Port
Green/
Orange
Solid Green Port is operating at 100 Mbps
Solid Orange Port is operating at 1000 Mbps
Light Off Port is operating at 10 Mbps
Link and
TX/RX of
SFP Port
Green/
Orange
Solid Green Port is operating at 100 Mbps
Blinking Green Port is sending or receiving data at 100 Mbps
Solid Orange Port is operating at 1000 Mbps
Blinking Orange Port is sending or receiving data at 1000 Mbps
Default Interface Settings
Ethernet Interface Interface Type IP Address Web-Based
Management
LAN (1-4) Static IP 192.168.10.1/24 Enabled
Installation and Connection
Before You Begin
Observe the following precautions to help prevent shutdowns, equipment failures, and injuries:
• Before installation, always check that the power supply is disconnected.
• Ensure that the room in which you are operating the device has adequate air circulation and that the room
temperature does not exceed 40 °C (104 °F).
• Ensure there is at least one meter (three feet) of clear space in front and back of the device.
• Do not place the device in an equipment rack frame that blocks the air vents on the sides of the chassis.
Ensure that enclosed racks have fans and louvred sides.
• Ensure that none of these hazardous conditions exist before installation: moist or wet floors, leaks,
ungrounded or frayed power cables, or missing safety grounds.
