Unied Access Point Administrator’s Guide
Unied Access Point Administrator’s Guide
Page 124
January 2015
Appendix B - Conguration Examples
Figure 81 - Congure Client QoS DiffServ Policy Map Settings (Rule)
10.) For the class_voip Class Map, select the Mark IP Dscp option, and then select ef from the Select From List
menu.
11.) Trafc that meets the criteria dened in the class_voip class is marked with a DSCP value of EF (expedited
forwarding).
12.) Click Apply to save the policy.
13.) Navigate to the Client QoS > VAP QoS Parameters page.
Figure 82 - Congure Client QoS VAP Settings
14.) Select VAP 2 from the VAP menu.
15.) Make sure that the Client QoS Global Admin Mode and the QoS Mode are both enabled.
16.) From the DiffServ Policy Up menu, select pol_voip.
17.) Click Apply to update the AP with the QoS settings.
Conguring QoS by Using the CLI
ACL Conguration
1.) Connect to the AP.
2.) Create an ACL named acl1.
add acl acl1 acl-type ipv4
3.) Add a rule to acl1 that allows HTTP trafc from the 192.168.1.0 subnet.
add rule acl-name acl2 acl-type ipv4 action permit protocol ip src-ip 192.168.1.0 src-ip-
mask 0.0.0.255 src-port http
